Model No. |
PCT 8 |
PCT 12 |
PCT 25 |
|---|---|---|---|
| Tapping Cap. | 8mm | 12 mm | 25 mm |
| Pillar Diameter | 43 mm | 74.5 mm | 89 mm |
| Spindle Nose to Bed Distance | 216 mm | 445 mm | 525 mm |
| Distance From Spindle | 130 mm | 191 mm | 250 mm |
| Centre to Piller Surface | 150 mm | 254 mm | 254 mm |
| Head Travel | ER 20 | MT.3 | MT .4 |
| Number of Speed | 4 | 8 | 8 |
| Range of Speed (in R.P.M) 1440 | 2,52,39,05,90,912 | 125,215,350,573 | 76,125,190,287, |
| Range of Speed (in R.P.M) 1440 | 190,325,525,860 | 115,187,287,430 | |
| Spindle Travel | 70 mm | 90 mm | 125 mm |
| Pillar Length | 530 mm | 800 mm | 1000 mm |
| Overall Height with Pulley Grand | 800 mm | 1100 mm | 1500 mm |
| Ram Diameter | 49 mm | 58 mm | 68 mm |
| Table Size | A85 X 220 mm | 350 x 370 mm | 600 X 600 mm |
| Adopter | ER 20 | ER 32 | ER 40 |
| V-Balt Size | A/ 26 | A / 45 | B/54 |
| Weight (approx) | 70 KG | 120 Kg | 225 Kg |
| Motor 3 Phase 440 Volts | 0.5 HP 960 RPM | 1.25HP 960 RPM | 2 HP 960 RPM & |
| Double Speed | Single Speed | 2HP 1440 RPM | 3 HP 1440 RPM |
| Pitch in (mm) | .35,.4,.5,.6,.75,1.0,1.25 | .5, .75, 1, 1.25, .1.5,1.75 | .5, .75, 1, 1.25, .1.5,1.75,2,3 |
| Pitch in (Inch) | 12, 14, 16, 18, 20, 22 | 8,10,12 12, 14, 16, 18, 20, 22 |
