Model No. |
SL13 |
SH 15 |
S- 20 |
SHG 25 |
S 32 |
SHG 40+50 |
|---|---|---|---|---|---|---|
| Drilling Cap. | 13 mm | 15 mm | 20 mm | 25 mm | 32 mm | 50 mm |
| Pillar Diameter | 46.5 mm | 58.5 mm | 74.5 mm | 88 mm | 88 mm | 112.5 mm |
| Spindle Nose to Table Distance | 360 mm | 445 mm | 700 mm | 750 mm | 590 mm | 590 mm |
| Distance From Spindle Centre to Piller Surface | 154.5 mm | 177 mm | 191 mm | 225 mm | 261 mm | 299 mm |
| Table Travel | 350 mm | 280 mm | 419 mm | 419 mm | 465 mm | 465 mm |
| Taper in Spindle | Jt6 & Mt2 | MT.2 | MT.3 | MT.3 | MT.4 | MT.5 |
| Number of Speed | 5 | 4 / 8 | 4/8 | 8 | 8 | 8 |
| Range of Speed (in R.P.M) | 570 to 2750 | 500 to 2160 90 to 2900 |
580 to 2600 75 to 3000 |
70 to 2500 | 65 to 2200 | 55 to 1500 |
| Spindle Travel | 95 mm | 95 mm | 144 mm | 165 mm | 254 mm | 254 mm |
| Pillar Length | 750 mm | 840 mm | 1200 mm | 1200 mm | 1448 mm | 1525 mm |
| Overall Height with Pulley Grand | 920 mm | 1200 mm | 1400 mm | 1620 mm | 1780 mm | 1880 mm |
| Ram Diameter | 49.5 mm | 49.5 mm | 58 mm | 58 mm | 68 mm | 74.5 mm |
| Table Size in Diameter | 215 mm | 250 mm | 300 | 350 | 450 mm | 465 mm |
| Base Size (Machined Area) (in mm) | 162 x 162 | 171 x 280 | 210 x 210 | 285 x 445 | 290 x 290 | 350 x 394 |
| Overall Base Size (in mm) | 230 x 360 | 254 x 432 | 290 x 475 | 285 x 600 | 400 x 510 | 483 x 750 |
| V-Balt Size | A-34 | A-37 | B-46 / A 43 | B-48 | B 52 | B-62 |
| 60 / 70 Kg | 100 Kg | 140 Kg |
|
285 Kg | ||
| Weight (approx) | .5HP 1440 RPM | 1HP 1440 RPM | 1.5HP1440 RPM | 160 Kg | 2 HP 960 RPM | |
| Motor 3 Phase 440 Volts | .5 HP 1440 RPM | 12 mm | 14mm | 25 mm | 2HP1440 RPM | 50 mm |
| Tapping Cap. | 8 mm | .5 HP 960 RPM | 1 HP 960 | 1.5 hp 960 | 40 mm | 2 HP 960 |
| Tapping Motor | .5 HP 960 RPM | 2 HP 960 |
