Model No. |
Duplex 4 - 25 |
Duplex 2- 50 |
Duplex 2- 60 |
|---|---|---|---|
| Max Drilling Dia | 25 mm | 50 mm | 60 mm |
| Number of Spindle | 4 | 2 | 2 |
| Distance Between Spindle Bed | 130 mm | 130 mm | 150 mm |
| Max Spindle Speed | 3200 | 3200 | 2800 |
| Spindle Bor | 32mm | 50 mm | 50 mm |
| Each Spindle Power | 5HP | 10HP | 15HP |
| Ball Screw Dia | 40X10 | 40X10 | 40X10 |
| LM Guide way | 45 mm | 45 mm | 45 mm |
| Servo Motor | 1 k.w | 1 k.w | 1.5 k.w |
| ZAXIS Travel | 300 mm | 400 mm | 450 mm |
| ZAXIS Travease Rate | 3600 mm per minute | 3600 mm per minute | 3600 mm per minute |
| Bed Size | 250X450 | 250X450 | 300X450 |
| Coolent Size | 1.5 kw 2 NoS | 1.5 kw 2 NoS | 1.5 kw 2 NoS |
| Working Table Height | 38" | 38" | 38" |
| Total Machine Power | 29HP/25KW | 29HP/23KW | 37HP/30KW |
| Machine Weight (approx) | 2300 kg | 2500 kg | 3000 kg |
| Overall Dimension | H.1900xL3500xW1600 | H.2000xL3800xW1800 | H.2000xL4000xW900 |
