Model No. |
MAG-16 |
MAG-25 |
MAG-40 |
MAG-50 |
|---|---|---|---|---|
| Max Drilling Dia | 18 X D3 | 25 X D3 | 40 X D3 | 50 X D3 |
| Number of Spindle | 2 | 2 | 2 | 2 |
| Distance Between Spindle Bed | 40X 60 | 60 X 80 | 80 X 120 | 100 X 150 |
| Max Spindle Speed | 3000 | 3000 | 2400 | 2400 |
| Spindle Bor | 32 mm | 32 mm | 40 mm | 50 mm |
| Each Spindle Power | 3 HP X 2 | 5 HP X 2 | 7.5 HP X 2 | 10 HP X 2 |
| Ball Screw Dia | 25 X 10 | 32 X 10 | 40 X 10 | 40 X 10 |
| LM Guide way | 25 mm | 35 mm | 45 mm | 55 mm |
| Servo Motor | 400 Watt. | 750 Watt. | 750 Watt. | 1 k.w |
| ZAXIS Travel | 01:10 | 01:10 | 01:10 | 01:10 |
| ZAXIS Travease Rate | 300 mm | 350 mm | 350 mm | 400 |
| Bed Size | 3000 mm per minute | 3000 mm per minute | 2400 mm per minute | 2000 mm per minute |
| Coolent Size | 1 k.w 1 NoS | 1 k.w 1 NoS | 1.5 k.w 1 NoS | 2 k.w 1 NoS |
| Working Table Height | 36" | 36" | 36" | 36" |
| Total Machine Power | 2000x900x1700 | 2000x900x1700 | 2000x900x2000 | 2000x900x2000 |
| Machine Weight (approx) | 10HP | 15HP | 22HP | 27HP |
| Overall Dimension | 1300 KG | 1500 KG | 1800 KG | 2000 KG |
