Model No. |
HD 2-16 |
HD 2-25 |
HD 2-40 |
HD 2-60 |
|---|---|---|---|---|
| Max Drilling Dia | 16 | 25 | 40 | 60 |
| Number of Spindle | 2 | 2 | 2 | 2 |
| Distance between Spindles | 150 | 200 | 250 | 300 |
| Nos. of Spindle Speed | 4 | 2 | 2 | 2 |
| Spindle Taper | M12 | MT3 | MT4 | MT5 |
| Spindle Power | 2HP | 5HP | 7.5HP | 10 HP |
| LM Guideway | Pilar 88mm & 112mm a | 35mm | 45mm | 55mm |
| ZAXIS Travel | 150mm | 300 | 400 | 450 |
| Bed Size | 380x380 & 450x600 | 450x600 | 450x700 | 500x750 |
| Working Table Height | 36" | 36" | 36" | 36" |
| Overall Dimension | 2000x1700x2000 | 2300x1700x1900 | 2400x1700x1900 | 2600x1700x2000 |
| Total Machine Power | 4.5HP | 7.5 HP | 10 HP | 14 HP |
| Weight (approx) | 300 Kg | 1000 kg | 1300 kg | 2000 kg |
